The new wall-mounted contactless sensor COOL TOUCH™ devices are a compact solution for public and commercial premises, providing convenient filling of bottles and other containers and unlimited access to pure drinking water.
The device is equipped with a professional 3-in-1 water filtration system (sediment, carbon and membrane filters), which effectively purifies water from various contaminants and impurities, including microplastics. Moreover, highly effective UV-C sterilization provides additional microbiological protection.
uninterrupted water supply and high performance of the equipment are important
space is limited and there is no possibility to install a free-standing device
a high level of hygiene, reliability and ease of operation are requiredCOOL TOUCH™ sensor stations for filling bottles are suitable for installation in any premises with a connection to a centralized water supply system. Their compliance with quality and safety standards ensures reliable and hygienically safe use even in environments with increased sanitary requirements.
health care
office buildings
government
municipal
industrial
educational
sports and
hotels and fieldThis is a modern solution for public and commercial premises, as it provides a technologically sophisticated solution for daily use, combining the advantages of a compact size with high functionality and reliable operation in the long term.
Compact solution for premises with limited space
Dispense of pure water directly into a bottle with contactless activation or into a sink with a drinking fountain
Automatically shuts off water supply after 120 seconds to reduce consumption of resources
Mobile application with Bluetooth connection to monitor status of the device and water consumption
High water pressure* for efficient and fast operation under intensive load conditions
Adapted for easy access for people with functional impairments
Highly effective antimicrobial water treatment with UV-C LEDs to ensure microbiological safetyHigh-quality filter that removes a wide range of impurities, including microplastics
Special stainless steel alloy for safe and long-term contact with various types of food products
Solution that promotes the use of reusable containers and reduces the consumption of disposable PET bottles
Housing made of high-quality steel and impact-resistant polyplastic ensures a long service life under high load conditions
The absence of moving parts in the design reduces the risk of damage due to malicious actions or vandalism* depends on the building's water supply parameters
COOL TOUCH™ sensor bottle filling stations with supply of water of room temperature are available in two versions – with a sink and without it. The model without a sink is designed only for convenient and quick filling of bottles and other containers, and the model with a sink is additionally equipped with a drinking fountain, allowing you to drink directly from the device.
Model: CTF-14B-A2
| Type | wall mount |
| Types of water supply | sensor bottle filling station |
| Water source | centralized water supply system |
| Operating pressure | 100 – 400 kPa |
| Housing material | stainless steel of grade SUS304, polyplastic |
| Microbiological protection | UV-C sterilizer |
| Temperature of water dispensed | water of room temperature |
| Average productivity* | 110 l/h |
| Filtration system | professional 3-in-1 filter Microfilter FX-10 |
| Filter service life | up to 30,000 litres |
| Dimensions (without / with packaging) | 458 x 204 x 650 mm / 480 x 240 x 680 mm |
| Weight (without / with packaging) | 10 kgs / 12 kgs |
| Power supply | 220 V |
Model: CTF-14B-A1
| Type | wall mount, with sink |
| Types of water supply | drinking fountain, sensor bottle filling station |
| Water source | centralized water supply system |
| Operating pressure | 100 – 400 kPa |
| Housing material | stainless steel of grade SUS304, polyplastic |
| Microbiological protection | UV-C sterilizer |
| Temperature of water dispensed | water of room temperature |
| Average productivity* | 110 l/h |
| Filtration system | professional 3-in-1 filter Microfilter FX-10 |
| Filter service life | up to 30,000 litres |
| Dimensions (without / with packaging) | 470 × 480 × 999 mm / 500 × 500 × 1050 mm |
| Weight (without / with packaging) | 20 kgs / 22 kgs |
| Power supply | 220 V |
* depends on the building's water supply parameters
COOL TOUCH™ sensor bottle filling stations are equipped with a built-in professional three-stage filter that improves the quality of water from the central water supply system. The filtration system purifies water from mechanical impurities, chlorine, unpleasant odours and taste disturbances, from bacteria, viruses and other contaminants, as well as from microplastics, while preserving natural minerals and salts that are important for the body. As a result, we get pure, safe and pleasant-tasting drinking water.
All equipment has been manufactured in accordance with international requirements for quality, safety, hygiene, and environmental sustainability. This is confirmed by a number of certificates that both apply to the materials and components used and confirm the compliance of the final product with the regulatory standards of a number of countries. The certificates guarantee that the devices meet high safety and health protection criteria.
ISO 9001 is an international standard based on the key principles of a quality management system, including customer focus, active participation of top management, a process approach, and continuous improvement.
The CQC certificate confirms that the products comply with established quality, safety, and environmental standards. This voluntary certification demonstrates the manufacturer’s desire to ensure a higher level of quality than required by mandatory regulations.
RoHS is a marking certifying that the product has been developed in accordance with the directives of the European Union and is safe for health and the environment and confirming limited use of certain substances – such as lead, mercury and cadmium – in electrical and electronic equipment.
NSF International has been protecting and promoting human health worldwide since 1944. It is involved in the development of public health standards and carries out testing, auditing and certification of products and services.
CE marking is an administrative marking indicating compliance with health, safety and environmental requirements for products sold in the European Economic Area (EEA).
CB certificate confirms the compliance of equipment with international safety standards. It is recognized in more than 50 countries, guaranteeing proven quality and reliability in various markets.
The COOLTOUCH mobile application is available free of charge for both iOS users in the Apple App Store and Android users in the Google Play Store in Latvian, English, Russian and Estonian languages.
The application allows you to conveniently check the resource status of the equipment filters and promptly notice the need for their replacement, as well as to get information on the amount of water consumed.
Find out more about the available types of COOL TOUCH™ devices in the catalogue on our website or by contacting your manager / calling 67344444. Our specialists will provide detailed information about the available solutions and help you choose the most suitable one, considering all your needs.
